SKU: C55ZG0
Builders Prop 2.9m to 5.0m Size 5 supports formwork at height with the load capacity and certification that taller pours demand. A prop without a proven safety margin at extended height risks failure under the weight of deck concrete forming, and a poorly designed pin system can crush a hand during adjustment. This Amadio-manufactured prop is certified to European Norm DIN EN1065 by the Landesstelle für Bautechnik testing institute in Stuttgart, carrying a load capacity from 10.9 to 35kN. Its inner and outer steel tubes are grade S235JRH and S275JRH to UNI EN 10219-1/2, adjusted via a self-cleaning external thread, and its hand scissor safety and disengagement system protects the operator during setup and strike. Builders reach for it wherever taller formwork needs certified, high-capacity support.
Need a quote? Simply add to cart and you have the option to request a quote before checkout
Builders Prop 2.9m to 5.0m Size 5 supports formwork at height with the load capacity and certification that taller pours demand. A prop without a proven safety margin at extended height risks failure under the weight of deck concrete forming, and a poorly designed pin system can crush a hand during adjustment. This Amadio-manufactured prop is certified to European Norm DIN EN1065 by the Landesstelle für Bautechnik testing institute in Stuttgart, carrying a load capacity from 10.9 to 35kN. Its inner and outer steel tubes are grade S235JRH and S275JRH to UNI EN 10219-1/2, adjusted via a self-cleaning external thread, and its hand scissor safety and disengagement system protects the operator during setup and strike. Builders reach for it wherever taller formwork needs certified, high-capacity support.
| Specification | Details |
|---|---|
| Extension Range | 2.9 - 5.0 m |
| Inner Tube Diameter | 48.3 mm |
| Outer Tube Diameter | 60.3 mm |
| Weight | 20 kg |
| Steel Grade | S235JRH / S275JRH |
| Certification | DIN EN1065 |
| Load Capacity | 10.9 - 35 kN |
Download your Builders Prop - 2.9m - 5.0m Size 5 resources:
Builders Prop - 2.9m - 5.0m Size 5 does not have any Safety Data Sheets. Request here
About Builders Prop - 2.9m - 5.0m Size 5
2.9m to 5.0m, weighing 20kg.
10.9 to 35kN, certified to European Norm DIN EN1065.
A hand scissor safety and disengagement system protects the operator's hand during adjustment.
Yes, Powerpac stocks Economy Builders Props from 1.52m up to 3.5m for lower-height applications.
