SKU: 6190-UBOLT100
The U Bolt 100x 28mm x 12mm is a heavy-duty splicing jointer for connecting a pair of reinforcing steel bars in a rebar cage. Cages built in tight bays or against existing structure often can't be spliced with a full lap length, and a jointer that doesn't grip the bar securely risks slipping under load during casting. This U bolt has a 28mm wide, 80mm long opening that caters for splicing up to 2 x 25mm rebars, with an M10 thread bolt drawing a 45mm wide, 95mm long, 10mm thick galvanised steel washer/keeper plate down against the bars. The galvanised coating on both the bolt and keeper plate resists corrosion in the same wet, abrasive conditions the surrounding rebar cage is exposed to. Steel fixers and precasters use it wherever cages need to be spliced in confined bays or tight working areas rather than run with a continuous bar.
Need a quote? Simply add to cart and you have the option to request a quote before checkout
The U Bolt 100x 28mm x 12mm is a heavy-duty splicing jointer for connecting a pair of reinforcing steel bars in a rebar cage. Cages built in tight bays or against existing structure often can’t be spliced with a full lap length, and a jointer that doesn’t grip the bar securely risks slipping under load during casting. This U bolt has a 28mm wide, 80mm long opening that caters for splicing up to 2 x 25mm rebars, with an M10 thread bolt drawing a 45mm wide, 95mm long, 10mm thick galvanised steel washer/keeper plate down against the bars. The galvanised coating on both the bolt and keeper plate resists corrosion in the same wet, abrasive conditions the surrounding rebar cage is exposed to. Steel fixers and precasters use it wherever cages need to be spliced in confined bays or tight working areas rather than run with a continuous bar.
| Specification | Details |
|---|---|
| Opening Width | 28 mm |
| Opening Length | 80 mm |
| Keeper Plate | 45mm x 95mm x 10mm |
| Thread | M10 |
| Rebar Capacity | Up to 2 x 25mm |
| Coating | Galvanised |
Download your U Bolt 100x 28mm x 12mm resources:
U Bolt 100x 28mm x 12mm does not have any Safety Data Sheets. Request here
About U Bolt 100x 28mm x 12mm
It's a heavy-duty jointer for splicing two reinforcing steel bars together in a rebar cage.
Its 28mm wide, 80mm long opening caters for splicing up to 2 x 25mm rebars.
It uses an M10 thread.
The keeper plate is a 45mm wide, 95mm long, 10mm thick galvanised steel plate that the bolt draws down against the spliced bars to clamp them together.
Yes. Both the bolt and keeper plate have a galvanised coating.
